Cone Crusher

CM Series™ Cone Crusher

Crushing Reinvented with Multi-Actuator Technology

The Taurian CM Series™ Cone Crusher is engineered for the toughest crushing conditions, delivering unmatched power and control through its Multi-Actuator Technology. Designed for large-scale mining and hard rock applications, it ensures high crushing force, precise CSS control, and superior durability—making it ideal for extreme secondary and tertiary operations.

Key Benefits

Efficient and Versatile Crushing for Demanding Applications

High-Efficiency Crushing Powered by Roller Bearing Technology

What We Offer

Heavy-Duty Core. High-Performance Results.

With a fixed main shaft and Multi-Actuator Technology, the CM Series™ ensures constant crushing force. Its bolted mainframe and hydraulic systems enable stable chamber operation, efficient reduction, and high reliability in demanding secondary and tertiary crushing applications.

Product Features

Engineered for safe, seamless operation—making crushing simpler and more efficient.

Hydraulic Cylinders for Clamping and Clearing

The CM Series™ is equipped with robust hydraulic cylinders for reliable clamping of the bowl and rapid chamber clearing. This enables faster maintenance, reduced downtime, and safer operations—especially during tramp iron release or routine liner replacement in high-duty crushing environments.

Hydraulic Motor for Bowl Rotation

A powerful hydraulic motor rotates the bowl for CSS adjustment—allowing fine control over output size without stopping the crusher. This also enables quick liner changes and resetting after tramp events.

Easy Maintenance with Hydraulic Bowl Rotation

CM Cone features a hydraulically driven bowl rotation system, allowing quick and safe adjustment or removal of the bowl and mantle liners. This design significantly reduces maintenance time, enhances safety, and simplifies liner replacement during routine service or wear part changes.

Labyrinth Seals

Equipped with precision-engineered labyrinth seals that prevent dust and moisture ingress into the bearing assembly. This ensures longer bearing life, reduced wear, and improved reliability in harsh crushing environments.

Hydraulic Cylinders

Hydraulic Motor for Bowl Rotation

Hydraulic Bowl Rotation

Labyrinth Seals

Product Gallery

Technical Specifiactions

Capacity Chart
Crusher Weights

Capacity Chart

Tone/ hour	CM100	CM200	CM300	CM400	CM500	CM800
Size	Mtph	Mtph	Mtph	Mtph	Mtph	Mtph
Size	stph	stph	stph	stph	stph	stph
6 mm (1/4”)	45-55
6 mm (1/4”)	50-60
8 mm (5/16")	50-60
8 mm (5/16")	55-65
10 mm (3/8")	55-70	90-120	115-140	140-175	175-220	260-335
10 mm (3/8")	60-75	100-130	125-155	155-195	195-240	285-370
13 mm (1/2")	60-80	120-150	150-185	185-230	230-290	325-425
13 mm (1/2")	65-90	130-165	165-205	205-255	255-320	360-470
16 mm (5/8")	70-90	140-180	140-180	225-280	280-350	385-500
16 mm (5/8")	80-100	155-200	155-200	250-310	310-385	425-550
19 mm (3/4")	75-95	150-190	200-240	255-320	320-400	435-545
19 mm (3/4")	85-105	165-210	220-265	280-355	355-440	480-600
22 mm (7/8")	80-100	160-200	220-260	275-345	345-430	470-600
22 mm (7/8")	85-110	175-220	240-285	305-380	380-475	520-660
25 mm (1")	85-110	170-220	230-280	295-370	365-455	495-730
25 mm (1")	95-120	185-240	255-310	325-410	400-500	545-805
32 mm (1 1/4")	100-140	190-235	250-320	325-430	405-535	545-800
32 mm (1 1/4")	110-155	210-260	275-355	360-475	445-595	600-880
38 mm (1 1/2")		210-250	300-380	360-490	445-605	600-950
38 mm (1 1/2")		230-275	330-420	395-545	490-670	550-1045
45 mm (1 3/4")			350-440	410-560	510-700	690-1050
45 mm (1 3/4")			385-485	450-625	560-775	760-1155
51 mm (2")				465-630	580-790	785-1200
51 mm (2")				510-700	640-880	865-1320

Crusher Weights

Size	CM100	CM200	CM300	CM400	CM500	CM800
Crusher Complete	5 400 kg	10 400 kg	15 810 kg	23 000 kg	33 150 kg	68 650 kg
Crusher Complete	11 900 Lbs	22 960 Lbs	33 490 Lbs	50 600 Lbs	73 000 Lbs	151 200 Lbs
Bowl, Bowl Liner,Adj. Cap, Hopper	1 320 kg	2 680 kg	3 525 kg	4 800 kg	7 200 kg	17 350 kg
Bowl, Bowl Liner,Adj. Cap, Hopper	2 910 Lbs	5 915 Lbs	7 765 Lbs	10 575 Lbs	15 800 Lbs	38 220 Lbs
Head Mantle and Feed Plate	600 kg	1 200 kg	2 060 kg	3 240 kg	5 120 kg	10 800 kg
Head Mantle and Feed Plate	1 325 Lb	2 650 Lbs	4 550 Lbs	7 130 Lbs	11 280 Lbs	23 790 Lbs
Maximum recommended Power	90 kW	132 kW	200 kW	355 kW	355 kW	600 kW
Maximum recommended Power	125 HP	200 HP	300 HP	500 HP	500 HP	800 HP
Countershaft Speed-rpm	750-1200	750-1200	700-1200	700-950	700-950	700-950
