Taurian Sizer

Optimized Crushing for Coal, Bauxite, and Beyond

The Taurian Sizer is designed for controlled reduction of soft to medium-hard materials with minimal fines generation. Its twin-shaft design ensures uniform output, low power consumption, and gentle crushing action—making it ideal for coal, bauxite, and limestone. Compact, efficient, and reliable, it’s the smart choice for material conditioning and sizing.

Key Benefits

Shear power, controlled size.

Consistent product size with minimal fines and reduced dust generation.

What We Offer

Taurian Sizer – Shear Crushing for Wet and Sticky Feed

The Taurian Sizer is engineered for the controlled reduction of soft to medium-hard materials where conventional crushers fail. Operating on low-speed, high-torque principles, it features dual counter-rotating shafts fitted with intermeshing, wear-resistant teeth. This configuration applies shear and compression forces to break down material with high moisture, clay content, or cohesive properties.

Product Features

Engineered for safe, seamless operation—making crushing simpler and more efficient.

Rotating Blades for Consistent Size Reduction

The Taurian Sizer uses low-speed, high-torque rotating blades mounted on twin shafts to grip, shear, and crush material efficiently. This action minimizes fines while ensuring uniform output size—ideal for sticky, soft, or friable materials like coal, overburden, and bauxite in primary reduction stages.

Replaceable Wear Components

The sizer is designed with modular, bolt-on wear segments—including teeth, cheek plates, and shaft covers—that can be quickly replaced without welding. This reduces downtime, simplifies maintenance, and ensures continuous operation even in abrasive or high-moisture material handling environments.

Rotating Sizer Blades

Replaceable Wear Components

Product Gallery

Technical Specifications

SZ SERIES

SZ SERIES

Parameter	Value
Height	1590 mm
Width	3020 mm
Weight	60000 Kg
SZ Series	1000
Rings	6
Teeth Per Ring	3
Speed	25 rpm
Roll the Speed	1.5 m/s
Breaker Bar	Installed below crushing rolls, full width
Drive System Type	Electrical via Fluid Couplings
Drive Power/Voltage	400kW / 6.6 kV
Reducer in/Out Ratio	60/1 rpm
Reducer Torque	156 kN
Coupling	VOITH 650 TVSC fluid coupling / 450 kW
Lubrication System	Auto Grease Supply for crusher bearings
