Stackmax™

Radial Telescopic Conveyor

Radial

Engineered for high-volume, layered stockpiling with maximum flexibility and efficiency. With the ability to extend, retract, swivel, and elevate, it forms large, uniform stockpiles while reducing material segregation and compaction.

  1. Home
  2. Products
  3. Stackmax
  4. Radial Telescopic Conveyor
Radial
Key Benefits

Maximum Reach. Minimal Footprint.

Transforms stockpiling efficiency from the ground up

Radial
Extended Reach & Height
Extended Reach & Height

Stack up to 18.5 meters high with conveyor lengths up to 52 meters—ideal for high-volume applications.

Automated Operation
Automated Operation

Integrated control system ensures user-friendly, precise, and safe operation with programmable stacking sequences.

Minimized Segregation
Minimized Segregation

Telescopic radial design allows layered stacking to prevent fine/coarse material separation and optimize stockpile uniformity.

Low Maintenance, High Uptime
Low Maintenance, High Uptime

Dust-resistant housings, belt trainers, and cable support systems minimize downtime and maintenance effort.

Enhanced Safety
Enhanced Safety

Features like stinger safety stop, ultrasonic pile sensors, and undercarriage stability systems ensure safe operation at all times.

Radial
What We Offer

Reach farther. Stack smarter.

Ideal for bulk handling in mining, ports, quarries, and processing plants, the Radial Telescopic Conveyor minimizes loader use, reduces fuel consumption, and cuts rehandling costs. Its automation-ready system enables programmable stacking patterns for precise material control.

radial 50 50

Product Features

Engineered for safe, seamless operation—making stockpiling simpler and more efficient.

Radial conveyer

Telescopic Boom with Adjustable Discharge Height

This conveyor features a hydraulically or electrically extending boom along with variable elevation, enabling higher, wider, and layered stockpiles without repositioning—ideal for maximizing storage while minimizing material segregation.

Hytrolic wheel

Heavy-Duty Axle Assembly

Equipped with a robust axle and wheel configuration, the conveyor can be easily repositioned across the yard or site. The axle design supports towing, radial movement, and stable operation even on uneven terrain.

Stack pile capacity

Up to 30% More Stockpile Capacity

The radial and telescopic functionality allows the conveyor to build larger, more uniform stockpiles—delivering up to 30% more stockpile volume compared to conventional fixed-length conveyors.

Diffrent Pile stack shape 2

Multiple Stockpiling Patterns

Capable of creating conical, radial, kidney-shaped, or layered stockpiles through programmable control—ensuring optimal space utilization, reduced material segregation, and consistent product quality.

Telescopic Boom with Adjustable Discharge Height
Heavy-Duty Axle Assembly
Up to 30% More Stockpile Capacity
Multiple Stockpiling Patterns

Product Gallery

RADIAL 1
RADIAL 2
RADIAL 1
RADIAL 2

Technical Specifications

Operating Specifications
Specification35 (m)40 (m)45 (m)50 (m)
Conveyor Length (A)35404552
Highest Extended Discharge Height (B)13141618.5
Lowest Extended Discharge Height (C)4.14.34.84.5
Highest Retracted Discharge Height (D)7.889.511
Lowest Retracted Discharge Height (E)2.92.93.23.2
Anchor Pivot to Center of Axle (F)13.5151723
Weight Specifications
Weight at Axle - 900 mm Belt Width14,05015,60517,23520,865
Weight at Kingpin - 900 mm Belt Width8,3318,8458,4149,464
